Woods 35NX4.19XKDX1.31 Yoke Part # 105

Description

Part #: 105

Description: 35NX4.19XKDX1.31 Yoke

Notes:

• 35N = the 35N / 35-series driveline size (the U-joint/yoke series). This series has a centerline-to-end dimension commonly listed as 4.19″ for this style yoke.

• 4.19 = the centerline-to-end length of the yoke: 4.19 inches.

• KD = shorthand for a keyed bore (i.e., round bore with a keyway, usually retained with a set screw on these implement yokes). Retail listings commonly describe this style as “round bore” + “standard keyway and set screw.”

• 1.31 = the bore size in inches (decimal). 1.31″ is essentially 1-5/16″ (1.3125″) rounded.
